| Model | 4LZ-4.0E with canopy | |||
| Type | Self-propelled Whole-feeding | |||
| Dimension (Operation) | Length（mm） | 4960 | ||
| Width（mm） | 2890 | |||
| Height（mm） | 2700 | |||
| Weight（kg） | 3200 | |||
| Engine | Type | QUANCHAI C06-406 | ||
| Power（HP） | 88 | |||
| RPM（r/min） | 2650 | |||
| Fuel Capacity（L） | 130 | |||
| Gearbox | Hydraulic Gearbox Box ZKB85 | |||
| HST | 45cc | |||
| Chassis | Track(mm) | 450/500*90*51 | ||
| Track Center(mm) | 1150 | |||
| Ground Clearance(mm) | 320 | |||
| Harvesting | Cutting Width(mm) | 2100 | ||
| Feeding Capacity (kg/s) | 4.0 | |||
| Cutting Bar Lift | Hydraulic Control | |||
| Threshing | Type | Axial Flow Type with Beat Bars | ||
| Threshing Cylinder (mm) | 620*2000 | |||
| Filtrate Type | Vibrating Sieves+ Centrifugal Fan | |||
| Grain Tank Type | 360° Rotaty Unloading | |||
| Discharging | Grain Tank Volume(m³) | 1.5 | ||
| Work efficiency(acre/h) | 0.37-0.66 | |||
| Crops | Rice, Wheat, Rapeseed, Soybean | |||
1.Use 88HP turbo engine with high power and low fuel consumption
2.Cutting Width 2.1m for different areas of fields.
3.Reel uses spring type finger and PVC bush for better performance.
4.WORLD special hydraulic gear box 85 with best quality.
5.Use 45cc HST for working more smoothly.
6.Bigger threshing cylinder ensures grain less loss and much cleaner.
7.Grain tank capacity is 1.6m3 with 360 degree grain unloading.
8.Minimun ground clearance 360mm and rubber track 450/500*90*51 ensures machine work in deep mud field.
