| Model | WD1004 |
| Basic informatin | |
| Type | four-wheel drive |
| Dimension(mm) | 4440*2130*2760(reach to Safety frame) |
| Min Ground Clearance(mm) | 379 |
| Weight (kg) | 3800/4100(cabin) |
| Wheel Base Front/Rear(mm) | 1610/1620(normal) |
| PTO Speed(rpm) | 760/850 |
| Output Shaft Power(kw) | 72.5 |
| Clutch | Double |
| Canopy/Cabin | Canopy |
| Tires Standard(Front/Rear)(mm) | 13.6-24/16.9-34 |
| Maximum Hauling Force(kn) | 24.2 |
| No. of shift | 16/8 |
| Engine | |
| Engine Type | Inline,Water-cooling,4 Strokes |
| Engine Power (kw) | 81 |
| Rotation Rate (r/min) | 2300 |
| Fuel Tank Capacity(L) | 180 |
| Other Features | |
| Front Ballast | YES |
| Rear Ballast | YES |
| Standard Front/Rear Ballast(kg) | 320/360 |
| Maximum Front/Rear Ballast(kg) | 600/540 |
1. Adopt transmission 16+8 shuttle for easier operation which caters to different needs. And 24+24 shuttle is optional.
2. Good sealing performance of axles ensures it to work in deep mud field.
3. Adopt draft control for working smoothly.
4. Use rear double steering cylinders on front axle for reducing turning radius.
5.Air brake is optional for road transport.
6.High quality bearings are used for prolonging the work life.
7. Adopt technology of chassis of Italy Fiat for better performance.
9.Water tank uses three-dimensional dust proof net which enlarges air inlet area and also prevents debris from entering tank.
8. Cabin is optional.
