| SPECIFICATIONS | ||||
| 1 | Bucket capacity | 1.3m³ | ||
| 2 | Rated load | 2000kg | ||
| 3 | Transportation dimension（L×W×H） | 5910×1910×2810mm | ||
| 4 | Wheelbase | 2250mm | ||
| 5 | Thread | 1510mm | ||
| 6 | Max. breakout force | 48.87KN | ||
| 7 | Max. dumping height | 3200/3500mm | ||
| 8 | Dump distance | 885mm | ||
| 9 | Total time | 11.3s | ||
| 10 | Operating weight | 5500kg | ||
| Engine | ||||
| 1 | Model | WEICHAI HUAFENG R4105G57 | Cummins 4BT3.9-C100 | |
| 2 | Pattern | Inlineã€water-cooledã€4-strokeã€direct injection | ||
| 3 | Rated power/speed | 55kw/2200rpm | 75kw/2400rpm | |
| 4 | Max. torque | 275/261.7N.m | 330N.M | |
| 5 | Normal fuel consumption | 239/242g/kW.h | 203g/kW.h | |
| 6 | Total displacement | 4.4L | 3.9L | |
| 7 | Fuel | 0﹟或-10﹟ light diesel | ||
| Torque converter and transmission system | ||||
| 　1 | Model of torque converter | YJ280 | ||
| 2 | Pattern | 3-element single stage | ||
| 3 | Transmission type | Full-powershift, countershift type | ||
| 4 | Number of gear | 2 forward, 2 reverse | ||
| 5 | Max.travel speed | 24km/h | ||
| Alex | ||||
| 1 | Alex | Hualu | ||
| 2 | Main reducer pattern | Arc taper gear, moderation of first grade | ||
| 3 | Pattern of wheel side moderation | planet gear moderation of single | ||
| Tire | ||||
| 1 | Tire Size | 16/70-20 | ||
| Steering system | ||||
| 1 | Pattern | Articulated and hydraulic steering | ||
| 2 | Min. turning radius(outside of bucket) | 4500mm | ||
| 3 | Max. turning angle | 35º±1 | ||
| Hydraulic system | ||||
| 1 | Implement pump | CBF25 | ||
| 2 | Displacement | 25ml/r | ||
| 3 | System working pressure | 16MPa | ||
| 4 | Distribution device model | DF20.2C | ||
| Brake system | ||||
| 1 | Service brake | Air assisted oil disc on four wheel | ||
| 2 | Parking brake | flexible shaft control, outside bunch drum type | ||
1â—Torque converter and counter-shaft transmission gearbox-Komatsu technology, higher reliability and easier maintenance
2 â—Fully hydraulic steering system, power shift transmission, easier operation
3â—Bucket can be leveled automatically, optimized working device, higher productivity
4â—Comfortable operation environment, new design cabin, Grammer seat, air-conditioner at option
5 â—Various working devices of attachment are available, such as log clamp, pipe clamp, grass fork, plow, ore bucket, loose bucket, fork etc, to meet different needs
