| Overall Dimension | ||||||||||||||
| 1 | Length | 8630mm | ||||||||||||
| 2 | Width | 2600mm | ||||||||||||
| 3 | Height(To the top of the cab) | 3370mm | ||||||||||||
| 4 | Wheel base | 6100mm | ||||||||||||
| 5 | Tread | 2120(mm) | ||||||||||||
| Main Technical Specification | ||||||||||||||
| 1 | Operating weight | 14500kg | ||||||||||||
| 2 | Blade length | 3660mm | ||||||||||||
| 3 | Blade height | 545mm | ||||||||||||
| 4 | Shovel Blade thickness | 16mm | ||||||||||||
| 5 | Max lifting height | 450mm | ||||||||||||
| 6 | Max grading depth | 535mm | ||||||||||||
| 7 | Min. turning radius | 7300mm | ||||||||||||
| 8 | Pivot angle frame | +260 | ||||||||||||
| 9 | Max turning angle(front wheel) | +490 | ||||||||||||
| 10 | Oscillating angle of front axle | 320 | ||||||||||||
| 11 | Min ground clearance | 430mm | ||||||||||||
| 12 | Traveling speed(Km/h)，6 forward and 3 reverse | |||||||||||||
| (1) â… gear forward | 6.5 | |||||||||||||
| (2) â…¡ gear forward | 11.4 | |||||||||||||
| (3) â…¢ gear forward | 14.6 | |||||||||||||
| (4) â…£ gear forward | 24.8 | |||||||||||||
| (5) â…¤ gear forward | 30 | |||||||||||||
| (6) â…¥ gear forward | 49.2 | |||||||||||||
| (7) â… gear reverse | 6.5 | |||||||||||||
| (8) â…¡ gear reverse | 14.6 | |||||||||||||
| (9) â…¢ gear reverse | 30 | |||||||||||||
| Diesel engine | ||||||||||||||
| 1 | Model | Cummins 6BTA5.9-C180 | ||||||||||||
| 2 | Type | Direct injection. Turbocharged. Water cooling | ||||||||||||
| 3 | Rated output | 132 kW（180PS） | ||||||||||||
| 4 | Inter-bore of cylinder/Stroke | 102 /120 (mm) | ||||||||||||
| 5 | Total exhaust of cylinder | 5.9 (L) | ||||||||||||
| 6 | Power of start motor | 1.68(KW) | ||||||||||||
| 7 | Voltage of starting motor | 24(V) | ||||||||||||
| 8 | Rated speed | 2200(r/min) | ||||||||||||
| 9 | Max. Torque | >750(N.M) at 1300r/min | ||||||||||||
| 10 | Starting type | Electric电å¯åŠ¨ | ||||||||||||
| 11 | Min. specific fuel consumption | <220(g/Kw.h) | ||||||||||||
| 12 | Net weight | 590(kg) | ||||||||||||
| Transmission System | ||||||||||||||
| （一）Torque Converter | ||||||||||||||
| 1 | Model | WG180 （ZF technology） | ||||||||||||
| 2 | Type | 3-elements.single stage | ||||||||||||
| 3 | Torque ratio | 2.35 | ||||||||||||
| 4 | Cooling type | Pressure oil circulating | ||||||||||||
| (二)ã€Transmission case | ||||||||||||||
| 1 | Model | WG180 （ZF technology） | ||||||||||||
| 2 | Type | power shift, single-shift lever, natural-shift lock device | ||||||||||||
| 3 | Gear shift position | 6 Forward and 3 reverse gears | ||||||||||||
| (三)ã€Axle and Tire | ||||||||||||||
| 1 | Type of main reducer | spiral bevel gear, single stage | ||||||||||||
| 2 | Gear ratio of main reducer | 3.583 | ||||||||||||
| 3 | Type of final reducer | Single stage chain-drive | ||||||||||||
| 4 | Gear of ratio of final reducer | 3.75 | ||||||||||||
| 5 | Gear ratio | 13.436 | ||||||||||||
| 6 | Max. drawing force | 74.6KN | ||||||||||||
| 7 | Tandem drive | Double row roller-chains | ||||||||||||
| 8 | Size of tire | 17.5-25-12PR(standard) 13.00-24-12PR(optional) | ||||||||||||
| Working Device Hydraulic System | ||||||||||||||
| 1 | Model of oil pump(include steering pump) | CBGj2045/1025 | ||||||||||||
| 2 | System pressure | 175(kgf/cm2) | ||||||||||||
| 3 | Model of distribution valve | HUSCO5000-D | ||||||||||||
| 4 | Hydraulic lock | KAYABA technology | ||||||||||||
| 5 | Model of oil motor | EATON, JS-130 | ||||||||||||
| 6 | Blade load | 176kgf | ||||||||||||
| Steering System | ||||||||||||||
| 1 | Type | Fore Tire deflexion | ||||||||||||
| 2 | Model of steering gear | BZZ1-E160B+FKA-163022 | ||||||||||||
| 3 | System pressure | 15MPa | ||||||||||||
| Brake System | ||||||||||||||
| 1 | Type of traveling brake | Hydraulic assisted and inner-expanding brake | ||||||||||||
| 2 | Oil pressure | 100(kgf/cm2) | ||||||||||||
| 3 | Type of parking brake | Mechanical and inner-expanding brake type | ||||||||||||
| Oil Capacity | ||||||||||||||
| 1 | Fuel(diesel) | 330L | ||||||||||||
| 2 | Engine lubricating oil | 24L | ||||||||||||
| 3 | Oil for converter and gear box | 28L | ||||||||||||
| 4 | Oil for hydraulic system | 47L | ||||||||||||
| 5 | Oil for driving rear axles | 18L | ||||||||||||
| 6 | Balance box | 90L | ||||||||||||
· Sing-handle electro-hydraulic controlled power-shift T/M, 6forward &3reverse shifts makes operation easy and convenient
· Hydraulic lock, auto lock/unlock NO-SPIN differential ensures stability and powerful traction
· Ideal axle load allocation provides excellent stability while cutting hard surface
· Serviceable, efficient hydraulic system enables every part to be fully used
· Box-typed frame and advanced T/M enable it to complete heavy-duty work
· A wide working range is accomplished through flexible blade suspension system and articulated frame
