| Model | RC212 | |
| Operating weight | 12000 | kg |
| Diameter of vibrating drum | φ1500 | mm |
| Rolling width | 2100 | mm |
| Activating force | 260/132 | KN |
| Vibration frequency | 30 | Hz |
| Theoretical amplitude of vibration | 1.6/0.8 | mm |
| Moving speed Range I II III | 2.5/5.0/10.5 | km/h |
| backward I II | 2.5/5.0 | |
| Gradeability | 30% | |
| Diesel engine model | WP4G110E221 | |
| Rated rotation speed | 2000 | r/min |
| Rated power | 82 | kw |
| Overall dimensions L W H | 5850×2240× 3080 | mm |
| NO. | Name | Model | Unit | Manufacturer |
| 1 | engine | WP4G110E221 | 1 | WEICHAI |
| 2 | gearbox | CAP5-50GF05 | 1 | Changchun |
| 3 | Drive axle | CY1621 | 1 | Xuzhou |
| 4 | tire | 20.5-25 | 2 | Chaoyang |
| 5 | pump | P5100 | 1 | PERMCO |
| 6 | motor | M5100 | 1 | PREMCO |
| 7 | steering | BZZ1-E500A | 1 | Zhengzhou |
Main Features
1) Mechanical drive, three-speed gears.
2) Hydraulic vibration, electronic controlled delayed starting of vibration, great exciting force with high compacting efficiency.
3) Hydraulic steering, articulated frame with flexible steering and operation.
4) Adopt specific gearbox with synchronizer, big transmission torque, easy to shift gear.
5) Hydraulic clamp disc service brake, mechanical drum-style parking brake, safe and reliable.
6) Rear engine cover can be turned up for big angle for convenient maintenance.
7) Equipped with famous brand hydraulic components with reliable performance.
8) Tires with different tread patterns are optional.
9) Standard equipped with cabin, air conditioner is for your choice.
10) Road roller with padfoot is optional.
