Dongfeng Cummins engine with less oil consumption, low noise and emissions.

Transmission and torque converter of 5 ton loader are of good applicability.

Optimally designed working device and frames are stronger and more durable.

Heavy duty unloading hydraulic system improves the whole machine performance.

Best hydraulic cylinders, pumps and valve.

Bucket capacity: 1.8 m3

Rated load: 3.2 ton

Operation weight: 10.5 ton

Engine:

(1)Dongfeng Cummins 6BT5.9-C130

(2)Yuchai YC6B125-T10

Basic Data

Bucket Capacity                 1.8 m3

Rated Load                     3200 kg

Max. Traction                    97kN

Max. Break Out Force             100kN

Min. Turning Radius (outside tires)   5376mm

Max. Dumping Height             3060 mm

Max. Reach                     1008mm

Total Hydraulic Cycle Time         â‰¦10.3s

Full Bucket Lifting Time            â‰¦5.6s

Wheel Base                     2750mm

Dimensions (L*W*H)              6970*2460*3286mm

Min. Clearance Over Ground        360mm

Operating Weight                10500kg

Diesel Engine

Model                         Cummins 6BT5.9 or Yuchai YC6B125

Type                          Direct injection, water cooling,4 strokes

Rated Output                   97/92kw

Rated Speed                    2200rpm

Max. Torque                     560/460N.m

Transmission

Hydraulic Torque Converter Model   Single stage, two phase, four components

Transmission Type            2 forward and 1 reverse gears/hydraulic power shift, planet type

Forward 1st                    0-12km/h

Forward 2nd                    0-40km/h

Reverse 1st                     0-16km/h

Max. Permissible Temp            120℃

Axle & Tyre

Drive System                   4 wheel drive

Type of main Reducer            Spiral bevel gear, single stage

Type of hub Reducer             Planet gear

Tyre Size                       17.5-25-12PR

Energy-saving， money-saving and lower oil-consumption per hour than that of similar products

Good strength, sturdiness and durability, low operating cost and easy to keep maintenance;

Fully embody the people-oriented humanized design concept, improving the working environment of operators;

A balanced layout, advanced design matching, superior performance, strong mobility and high efficiency。
